Improved Sheet Support Paper Machine Fabric - Coarse 8/16 Shed DLA47816SM-420CFM with Additional CD Yarn for Superior Fiber Retention and Drainage in Board Production

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Structure:

Pattern Description:

Mesh × Count (l/cm):

Warp Diameter (mm):

Weft Diameter (mm):

Warp Material:

Air Permeability:

Caliper (mm):

Elongation(50N/cm):

Break Strength:

Fiber Support Index (FSI):

Drainage Index (DI):

Open Area:

Fabric Color:

Highlight:

8/16 Shed Design Forming Fabric

Additional CD Yarn Paper Machine Fabric

Superior Fiber Retention Kraft Paper Fabric

Product Description

KRAFT DLA47816SM-420CFM with Additional CD Yarn for Superior Fiber Retention and Drainage in Board Production

Engineered for demanding paper and board production, the KRAFT DLA47816SM is a double-layer forming fabric with an 8/16 shed design. Its key feature is an added CD yarn that significantly enhances fiber support and sheet quality. This configuration provides outstanding drainage alongside excellent life potential, thanks to the robust, large-diameter yarns employed on the wear side, making it ideal for packaging and wrapping paper grades.

Key Features

Enhanced Wear Side Design: 16-shed wear side weave incorporates an extra-long CD crimp, specifically engineered to accommodate large-diameter CD yarns
Maximized Fabric Life: Increased diameter and mass of the wear side yarns significantly boost abrasion resistance, extending operational lifespan

Product Parameters

Product Name	Forming Fabric KRAFT DLA47816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Applications

Wrapping and Packing Papers, Board Grades
