Triple layer Forming Fabrics For PRINT Paper

Product Details

Place of Origin: China

Brand Name: ATMC

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: inquiry

Packaging Details: Standard export ply-wood case

Delivery Time: 30 work days

Payment Terms: L/C,T/T

Supply Ability: Purchase supply

Get Best Price
Contact Now
Specifications
Highlight:

paper machine clothing 1020sp/cm2

,

400cfm paper machine cloth

,

400cfm paper machine clothing

Structure:
/
Pattern Description:
/
Mesh × Count (cm):
/
Warp Diameter (mm):
/
Weft Diameter (mm):
/
Warp Material:
/
Weft Material:
/
Air Permeability:
/
Caliper (mm):
/
Elongation (50N/cm):
/
Break Strength:
/
Fiber Support Index (FSI):
/
Fiber Support Point (SP):
/
Drainage Index (DI):
/
Paper Side Open Area:
/
Void Volume:
/
Weight (g/m2 ):
/
Fabric Color:
/
Structure:
/
Pattern Description:
/
Mesh × Count (cm):
/
Warp Diameter (mm):
/
Weft Diameter (mm):
/
Warp Material:
/
Weft Material:
/
Air Permeability:
/
Caliper (mm):
/
Elongation (50N/cm):
/
Break Strength:
/
Fiber Support Index (FSI):
/
Fiber Support Point (SP):
/
Drainage Index (DI):
/
Paper Side Open Area:
/
Void Volume:
/
Weight (g/m2 ):
/
Fabric Color:
/
Description
Triple layer Forming Fabrics For PRINT Paper

The PRINT SSB60205Y is a very fine two over five-shaft shute binding SSB triple layer with a 2:1 cross direction (CD) yarn ratio. The two-shaft paper side has paired CD binding yarns providing both extra support and binding the two independent layers together. The very high sheet support on the forming surface promotes excellent smoothness, formation, increased retention and minimal wire mark. High MD and CD stiffness for good wear potential and dimensional stability.

Seam Type: Joined Endless

Width: Up to 10.5 M

Applications: Printing and Writing Papers



Features and benefits:
1. Very fine plain weave top surface and
maximized fiber support for good retention and
very high sheet support.
2. Formation improvements and good printability.
3. Excellent sheet release.
4. High open area for high drainage capacity.
5. High MD and CD stiffness for dimensional
stability for dynamically stable under load and
speed.
6. Medium yarn diameter for good wear potential.

Applications:
Newsprint Paper, Printing & Writing paper, Board
Grades top layer, etc.


Paper SideWear Side
