BELT DW Series-1
BELT DW Series is the most widely used filter fabric suitable for a wide range of industrial applications, including the sludge dewatering in sewage plants with benefits High flow rate, Easy cleaning, Suitable for the majority of industrial applications.
BELT DW made of PET and PA with large diameters, press is highly resistant to abrasion.
Filter Press Belt can be widely applied in various sludge dewatering, such as municipal sludge, industrial sludge, agricultural sludge, and building sludge. Besides, it"s very helpful in residue treatment and suspension separation. When used as press belt, it contributes a lot to fruit and vegetable juice production. Moreover, its basic function as a conveyor belt helps a lot in food products transporting. In general, filter press belt can be applied in a variety of industries concerning dehydration, pressing and conveying.
Technical Parameters
|
Style |
Yarn Diameter (mm) |
Density (l/cm) |
Air Permeability |
Thickness (mm) |
Tensile (N/cm) |
Weight (g/m²) |
||||
|
Warp |
Weft |
Warp |
Weft |
m³/m²h |
CFM |
Fabric |
Seam |
|||
|
BELT 16903W |
0.70 |
0.90 |
16.3 |
5.0 |
7500 |
475 |
2.10 |
1600 |
900 |
1500 |
|
BELT 16903B |
0.70 |
0.90 |
16.3 |
6.0 |
4750 |
300 |
2.10 |
1600 |
900 |
1700 |
|
BELT 22903 |
0.50 |
0.90 |
23.0 |
5.5 |
8400 |
530 |
1.90 |
1600 |
900 |
1400 |
|
BELT 12904 |
0.90 |
0.90 |
12.3 |
9.5 |
9500 |
600 |
3.50 |
1600 |
900 |
2200 |
|
BELT 15905 |
0.90 |
0.90 |
15.3 |
5.0 |
7700 |
490 |
2.77 |
1600 |
900 |
2100 |
|
BELT 151105 |
0.90 |
1.10 |
15.3 |
6.3 |
9200 |
580 |
2.85 |
1600 |
900 |
2450 |
|
BELT 151105PA |
0.90 |
1.10 |
15.3 |
6.3 |
9200 |
580 |
2.85 |
1600 |
900 |
2450 |
|
BELT 31505 |
0.40 |
0.50 |
33.0 |
9.0 |
3000 |
190 |
1.30 |
1600 |
900 |
800 |
|
BELT 24808 |
0.50 |
0.80 |
24.8 |
8.0 |
7000 |
445 |
2.00 |
1600 |
900 |
1400 |
|
BELT 24908 |
0.50 |
0.90 |
24.8 |
7.1 |
7000 |
445 |
2.10 |
1600 |
900 |
1500 |
|
BELT 26508 |
0.50 |
0.50 |
28.0 |
18.5 |
2000 |
125 |
1.50 |
1600 |
900 |
1200 |
|
BELT 26908 |
0.50 |
0.90 |
26.5 |
6.2 |
6000 |
380 |
2.15 |
1600 |
900 |
1500 |
|
BELT 27708 |
0.50 |
0.70 |
28.0 |
8.5 |
4750 |
300 |
2.00 |
1600 |
900 |
1550 |
|
BELT 2470 |
0.50 |
0.70 |
24.0 |
9.0 |
7500 |
475 |
1.90 |
1600 |
650 |
1250 |
|
|
