Single Layer Design Forming Fabric KRAFT SL2105L with 5 Shed for Good Retention and Coarse Mesh Weave

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

Single Layer

Pattern Description:

5 Shed

MD Yarns Top:

MD Yarns Bottom:

CMD Yarns Top:

CMD Yarns Bottom:

Caliper (mm) New:

0.88

Caliper (mm) Critical:

Air Permeability:

475CFM, 7500m³ /m²h

Elongation(50N/cm):

≤0.50%

Break Strength:

≥850 N/cm

Fiber Support Index:

Fiber Support Point:

Drainage Index:

6.7

Paper Side Open Area:

13.4%

Void Volume:

Basis Weight (g/m²):

Fabric Color:

Light Green

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T

Highlight:

5 Shed Single Layer Design Forming Fabric

Good Retention Paper Machine Fabric

Coarse Mesh Weave Kraft Paper Fabric

Product Description

Forming Fabric KRAFT SL2105L - Good Retention 5 Shed Single Layer Design for Packaging Paper

Key Features

Good wear potential
Good machine and cross machine direction stability
Large weft yarn diameter for potential long life

Product Parameters

Product Name	Forming Fabric KRAFT SL2105L
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Light GSM Kraft Paper, Wrapping Paper, and similar paper manufacturing applications.
