Double Layer Advanced Drainage & Fiber Support Paper Machine Clothing - DLA47816SC-450CFM Coarse 8/16 Shed Fabric for Enhanced Performance in Wrapping Paper and Board Grades

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

Pattern Description:

Mesh × Count (l/cm):

Warp Diameter (mm):

Weft Diameter (mm):

Warp Material:

Air Permeability:

Caliper (mm):

Elongation(50N/cm):

Break Strength:

Fiber Support Index (FSI):

Drainage Index (DI):

Open Area:

Fabric Color:

Highlight:

coarse 8/16 shed fabric

drainage fiber support paper machine

wrapping paper board grades fabric

Product Description

KRAFT DLA47816SC-450CFM Coarse 8/16 Shed Fabric for Enhanced Performance in Wrapping Paper and Board Grades

Designed to optimize the papermaking process, the KRAFT DLA36816SL utilizes a unique double-layer weave (8-shed over 16-shed) supplemented with a supportive CD yarn. This achieves an optimal balance of high fiber retention and rapid water removal. The fabric’s longevity is ensured by coarse, high-mass weft yarns on the wear side, which provide increased resistance to abrasion and mechanical stress, ensuring reliable performance over time.

Key Features

High Mechanical Stability: Double MD yarn lock construction on the wear side provides robust resistance to high machine-direction (MD) loads.
Excellent Dimensional Stability: The durable wear side structure effectively resists cross-direction (CD) ridging, ensuring consistent, stable running.

Product Parameters

Product Name	Forming Fabric KRAFT DLA47816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Applications

Wrapping and Packing Papers, Board Grades
