The KRAFT DLA41816SL is engineered as a coarse 8-over-16 shed double-layer forming fabric. It incorporates an additional cross-direction (CD) yarn to enhance sheet support and formation stability. This specialized weave delivers outstanding drainage performance. Furthermore, the use of coarse, large-diameter weft yarns on the wear side significantly improves abrasion resistance, resulting in extended fabric service life.

Key Features

Enhanced Fiber Support & Drainage: Coarse 8-shed paper side structure uniquely delivers high fiber support alongside very high drainage capacity.

Optimized Surface for Drainage: The high top surface open area of the weave is engineered to facilitate rapid and efficient water removal.

Product Parameters

Product Name	Forming Fabric KRAFT DLA41816SL
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Wrapping and Packing Papers, Board Grades.

Tags:

Wrapping Papers Forming Fabric

Board Grades Forming Fabric

Double layer Forming Fabric For Wrapping and Packaging Papers, Board Grades

Get Best Price

Double layer Forming Fabrics For Wrapping and Packaging Papers, Board Grades

Get Best Price

Double layer Forming Fabrics For Wrapping and Packaging Papers, Board Grades,Kraft Paper

Get Best Price

Double layer Forming Fabrics For Wrapping and Packaging Papers, Board Grades

Get Best Price

Double layer Forming Fabric For KRAFT / Wrapping Paper

Get Best Price

Products Details

Home > Products >

Forming Fabrics

Double Layer Forming Fabric for Paper Making - 8/16 Shed KRAFT DLA41816SL-450CFM with Enhanced Sheet Support, Abrasion Resistant & Long Life

All Category

Forming Fabrics

Pulp Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Kraft & Packaging Grades (Brown Paper)

Single Layer

1.5 Layer

Double and Half Layer

Triple Layer / SSB

Publication Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Tissue Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Speciality Grades

Triple Layer / SSB

Press Felts

Pulp Grades

BOM Double Layer

BOM 1+1+1 Laminated

Kraft & Packaging Grades (Brown Paper)

BOM Double Layer

Dryer Fabrics

Woven with Flat Yarn

Double Cloth Design

Warp Float 1.5 Layer Design

Woven with Round Yarn

Double Layer

Spiral Linked with Flat Yarn

Spiral Linked with Round Yarn

Thin Ring

Small Ring

Middle Ring

Industrial Fabrics

Filter Cloth

Polyester Filter Cloth

Polypropylene Filter Cloth

Vinylon Filter Cloth

Non Woven Fabric

Spunbond/Meltblown

Airlaid

Spunlace

Wire Mesh

Stainless Steel Wire Mesh

Process Belts

Cylinder Mould Wire Mesh

Corrugated Belts

High Speed Fasttrack Cotton Belt

High-Speed Silencing Belt

Filter Belt

Industrial Felt Belts

Food Industry

Conveyor Belts

Stock Preparation Equipment

Pulping Equipment

Refining Equipment

Screening Equipment

Thickening Equipment

Cleaning Equipment

Paper Machine Components

Headbox

Dewatering System

Cover + Dewatering Box

Oscillating Shower

Dryer Cylinder

Rolls

Guide Roll

Suction Couch Roll

Bow Roll / Spreader Roll

Rewinder

Slitter Knife

Cylinder Mould

Paper Making Equipment Consumable Accessories

DDR Disc

Disc Filter Plate

Doctor Blade & Holder & Air Tube

Filter Bag

Paper Carrier Rope

Screen Basket

Screen Basket - Slot Type

Spray Shower / Nozzle

Double Layer Forming Fabric for Paper Making - 8/16 Shed KRAFT DLA41816SL-450CFM with Enhanced Sheet Support, Abrasion Resistant & Long Life

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

2.5 Layer

Pattern Description:

8/16 Shed

MD Yarns Top:

0.27mm 40.0 /cm PET

MD Yarns Bottom:

CMD Yarns Top:

0.20mm, 0.27mm 22.6 /cm PET

CMD Yarns Bottom:

0.50mm 11.3 /cm PET/PA

Caliper (mm) New:

1.450

Caliper (mm) Critical:

0.970

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.40%

Break Strength:

≥1100 N/cm

Fiber Support Index:

Fiber Support Point:

170 /cm²

Drainage Index:

22.2

Paper Side Open Area:

Void Volume:

811 Ml/m² (55.9%)

Basis Weight (g/m²):

850

Fabric Color:

Light Green, Light Blue

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T

Highlight:
