SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/10 Shed

MD Yarns Top:

0.17mm 25.0 /cm PET

MD Yarns Bottom:

0.25mm 25.0 /cm PET

CMD Yarns Top:

0.17mm 34.8 /cm PET/PA

CMD Yarns Bottom:

0.40mm 17.4 /cm PET/PA

Caliper (mm) New:

1.250

Caliper (mm) Critical:

0.870

Air Permeability:

400 CFM @ 125 Pa

Elongation(50N/cm):

≤0.40%

Break Strength:

≥900 N/cm

Fiber Support Index:

130

Fiber Support Point:

650 /cm²

Drainage Index:

26.4

Paper Side Open Area:

32.1%

Void Volume:

716 Ml/m²(51.3%)

Basis Weight (g/m²):

710

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer forming fabric

Kraft paper machine fabric

two shed ten shed fabric

Product Description

SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability

Designed for demanding paper making environments, KRAFT SSB60210WM features a two‑shed over ten‑shed shute binding as a standard SSB triple layer fabric. The fine paper side ensures even surface profiles and excellent fiber support, resulting in uniform formation. Its wear side incorporates an open, long‑float structure with a 3:2 CD shute ratio, enabling the use of medium and coarse CD yarns for extended life potential. Two MD thread systems deliver a stable construction with high CD stability. The open weave design facilitates high water removal rates and simplifies shower cleaning. This forming fabric offers outstanding durability, drainage, and sheet support.

Key Features

Dual MD thread systems ensure rigid fabric structure.
High CD stability reduces lateral movement during operation.
Medium CD yarns combined with long float improve wear resistance.

Product Parameters

Product Name	Forming Fabric KRAFT SSB60210WM
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
