1.5 Layer FLR2404 Dryer Fabric for Paper Making Machine with Warp Float Weave Structure Provides Smooth Sheet Surface, High Stability and Reliable Drying Performance for Paper Making Industry

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

1.5 Layer

Pattern Description:

Warp Float Weave

MD Yarns Top:

MD Yarns Bottom:

CD Yarns Top:

CD Yarns Bottom:

Caliper (mm) New:

1.80

Caliper (mm) Critical:

Air Permeability:

410/540 CFM 6500 / 8500m³/m²h

Elongation (50N/cm):

Break Strength:

≥1200 N/cm

Fiber Support Index (FSI):

Fiber Support Point (SP):

Drainage Index (DI):

Paper Side Open Area:

Void Volume:

Basis Weight (g/m² ):

1150/1100

Fabric Color:

Red, White

Highlight:

1.5 layer dryer fabric for paper making

FLR2404 dryer fabric with warp float weave

dryer fabric for paper industry with high stability

Product Description

1.5 Layer FLR2404 Dryer Fabric for Paper Making Machine with Warp Float Weave Structure Provides Smooth Sheet Surface, High Stability and Reliable Drying Performance for Paper Making Industry

The Dryer Fabric FLR2404 series dryer fabric is a warp float design constructed with round polyester machine direction yarns and round cross machine direction yarns, providing reliable strength, dimensional stability and consistent performance across a wide range of permeability. The optimized weave pattern delivers a smooth surface, improved sheet handling and efficient drying performance for modern paper making machines.

Benefits and Features

Warp float weave for smooth sheet handling.
Polyester MD and CMD yarn construction.
Excellent strength and dimensional stability.
High resistance to distortion and wrinkling.

Product Images


Paper Side	Inline Spiral Seam

MD Contour

Applications

Any conventional dryer section for Wrapping and Packaging Papers, Board Grades, Printing &Writing Papers.
