Double Layer Forming Fabric Featuring High Air Permeability and Excellent Drainage Capacity with Double MD Yarn Lock Structure for Stable Paper Machine Operation

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

2.5 Layer

Pattern Description:

8 Shed

MD Yarns Top:

0.17mm 62.0 /cm PET

MD Yarns Bottom:

CMD Yarns Top:

0.12mm, 0.18mm 34.0 /cm PET

CMD Yarns Bottom:

0.25mm 17.0 /cm PET/PA

Caliper (mm) New:

0.760

Caliper (mm) Critical:

0.540

Air Permeability:

400 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

120

Fiber Support Point:

395 /cm²

Drainage Index:

28.2

Paper Side Open Area:

Void Volume:

410ml/m² (54.0%)

Basis Weight (g/m²):

465

Fabric Color:

Light Green, Light Blue

Highlight:

Double layer forming fabric high air permeability

Double MD yarn lock fabric stable operation

Forming fabric excellent drainage capacity paper machine

Product Description

Double Layer Forming Fabric Featuring High Air Permeability and Excellent Drainage Capacity with Double MD Yarn Lock Structure for Stable Paper Machine Operation

The PRINT DLA67808DS58 features an eight shed double layer weave with extra cross direction yarns positioned on the paper side surface. These additional support yarns deliver good fiber retention while maintaining very good formation characteristics. High air permeability ensures the fabric achieves excellent drainage capacity, supporting efficient water evacuation even at elevated machine speeds. On the wear side, the double MD yarn lock creates a robust and dimensionally stable structure with good wear potential to withstand abrasive conditions. This fabric is well suited for demanding printing paper production environments.

Key Features

Excellent drainage capacity in the forming section
Double MD yarn lock on wear side for structural stability
Good wear potential for extended fabric service life
Optimized for high-speed printing and writing paper production

Product Parameters

Product Name	Forming Fabric PRINT DLA67808DS58
Material	Polyester monofilament
Function	Paper Machine
Application	Newsprint Paper, Specialty Papers, Tissue Papers, etc
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Newsprint Paper, Specialty Papers, Tissue Papers, etc
