The PRINT DLA67816SM features a sophisticated eight over sixteen shed double layer weave that combines high fiber support with very high drainage capacity. Extra CD yarns on the paper side optimize retention, while the sixteen shed wear side with large diameter CD crimp delivers superior wear potential. The more pronounced CD crimp on the machine side provides excellent protection for MD warp yarns and increases abrasion resistance for longer fabric life. The fabric's rugged design withstands high machine direction loads and offers outstanding resistance to CD ridging. This versatile fabric performs reliably across printing and writing paper, light weight kraft, and board grades including top and under-top layers.

Key Features

Robust construction withstanding high MD loads
Excellent resistance to CD ridging for dimensional stability
Optimized for printing and writing paper grades
Suitable for light weight kraft and board top and under-top layers

Product Parameters

Product Name	Forming Fabric PRINT DLA67816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..

Tags:

8 shed paper machine forming fabric

2.5 layer polyester forming fabrics

8 shed polyester forming fabrics

Double Layer Forming Wire with Robust Construction and High Fiber Support Offering Very High Drainage and Resistance to CD Ridging

Get Best Price

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Get Best Price

Paper Machine Double Layer Cloth with 8 Shed Support Side and 16 Shed Wear Side for Good Retention and Long Service Life Potential

Get Best Price

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

Get Best Price

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Get Best Price

Products Details

Home > Products >

Forming Fabrics

Double Layer Paper Making Wire with Enhanced Abrasion Resistance and High MD Load Capacity Featuring 8 over 16 Shed Weave Pattern

All Category

Double Layer Paper Making Wire with Enhanced Abrasion Resistance and High MD Load Capacity Featuring 8 over 16 Shed Weave Pattern

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

2.5 Layer

Pattern Description:

8/16 Shed

MD Yarns Top:

0.17mm 62.0 /cm PET

MD Yarns Bottom:

CMD Yarns Top:

0.12mm, 0.20mm 34.6 /cm PET

CMD Yarns Bottom:

0.35mm 17.3 /cm PET/PA

Caliper (mm) New:

0.990

Caliper (mm) Critical:

0.660

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

122

Fiber Support Point:

403 /cm²

Drainage Index:

25.8

Paper Side Open Area:

Void Volume:

528ml/m²(53.3%)

Basis Weight (g/m²):

615

Fabric Color:

Light Green, Light Blue

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T
