Designed as an eight over sixteen shed double layer fabric, the PRINT DLA67816SF offers a superior balance between retention and drainage. The fine mesh paper side with extra support shute yarns ensures good fiber retention, while the sixteen shed wear side weave provides good service life. Very high drainage capacity is achieved without compromising sheet formation quality. The machine side features a longer CD crimp with medium diameter yarns that increases wear yarn mass and enhances abrasion resistance. This robust construction maintains structural integrity under high MD tension and prevents CD ridging. This fabric is ideally suited for printing and writing papers and newsprint applications.

Key Features

High fiber support for excellent retention performance
Very high drainage capacity for rapid water removal
Pronounced CD crimp on machine side protecting MD warp yarns

Product Parameters

Product Name	Forming Fabric PRINT DLA67816SF
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc..
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..

Tags:

8 shed paper machine forming fabric

2.5 layer polyester forming fabrics

8 shed polyester forming fabrics

Double Layer Forming Wire with Robust Construction and High Fiber Support Offering Very High Drainage and Resistance to CD Ridging

Get Best Price

Double Layer Paper Making Wire with Enhanced Abrasion Resistance and High MD Load Capacity Featuring 8 over 16 Shed Weave Pattern

Get Best Price

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Get Best Price

Paper Machine Double Layer Cloth with 8 Shed Support Side and 16 Shed Wear Side for Good Retention and Long Service Life Potential

Get Best Price

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Get Best Price

Products Details

Home > Products >

Forming Fabrics

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

All Category

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

2.5 Layer

Pattern Description:

8/16 Shed

MD Yarns Top:

0.17mm 62.0 /cm PET

MD Yarns Bottom:

CMD Yarns Top:

0.12mm, 0.20mm 37.4 /cm PET

CMD Yarns Bottom:

0.30mm 18.7 /cm PET/PA

Caliper (mm) New:

0.910

Caliper (mm) Critical:

0.630

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

129

Fiber Support Point:

434 /cm²

Drainage Index:

27.7

Paper Side Open Area:

Void Volume:

489ml/m²(53.7%)

Basis Weight (g/m²):

560

Fabric Color:

Light Green, Light Blue

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T

Highlight:

double layer forming fabric

high drainage paper fabric

long CD crimp forming fabric

Product Description

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

Key Features

High fiber support for excellent retention performance
Very high drainage capacity for rapid water removal
Pronounced CD crimp on machine side protecting MD warp yarns

Product Parameters

Product Name	Forming Fabric PRINT DLA67816SF
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc..
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..
