The PRINT DLA67816SF is a double layer forming fabric engineered with a fine eight shed paper side weave over a sixteen shed wear side construction. The paper side features extra cross direction support yarns that deliver high fiber retention, while the robust wear side incorporates a pronounced CD crimp with medium diameter yarns for extended life potential. This unique combination achieves both high fiber support and very high drainage capacity within a single fabric design. The wear side's long CD crimp effectively protects MD warp yarns from abrasion. The robust construction withstands high MD loads and resists CD ridging, making this fabric particularly suitable for printing and writing paper as well as newsprint production.

Key Features

Eight over sixteen shed double layer weave construction
Fine mesh eight shed paper side with extra CD support yarns
Sixteen shed wear side weave for good service life

Product Parameters

Product Name	Forming Fabric PRINT DLA67816SF
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc..
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..

Tags:

8 shed paper machine forming fabric

2.5 layer polyester forming fabrics

8 shed polyester forming fabrics

Double Layer Forming Wire with Robust Construction and High Fiber Support Offering Very High Drainage and Resistance to CD Ridging

Get Best Price

Double Layer Paper Making Wire with Enhanced Abrasion Resistance and High MD Load Capacity Featuring 8 over 16 Shed Weave Pattern

Get Best Price

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Get Best Price

Paper Machine Double Layer Cloth with 8 Shed Support Side and 16 Shed Wear Side for Good Retention and Long Service Life Potential

Get Best Price

High Drainage Double Layer Forming Fabric Featuring 8 over 16 Shed Weave with Long CD Crimp for Extended Wear Life in Paper Production

Get Best Price

Products Details

Home > Products >

Forming Fabrics

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

All Category

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

2.5 Layer

Pattern Description:

8/16 Shed

MD Yarns Top:

0.17mm 62.0 /cm PET

MD Yarns Bottom:

CMD Yarns Top:

0.12mm, 0.20mm 37.4 /cm PET

CMD Yarns Bottom:

0.30mm 18.7 /cm PET/PA

Caliper (mm) New:

0.910

Caliper (mm) Critical:

0.630

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

129

Fiber Support Point:

434 /cm²

Drainage Index:

27.7

Paper Side Open Area:

Void Volume:

489ml/m² (53.7%)

Basis Weight (g/m²):

560

Fabric Color:

Light Green, Light Blue

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T

Highlight:

Double layer paper forming fabric

Eight over sixteen shed weave fabric

High fiber retention drainage fabric

Product Description

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Key Features

Eight over sixteen shed double layer weave construction
Fine mesh eight shed paper side with extra CD support yarns
Sixteen shed wear side weave for good service life

Product Parameters

Product Name	Forming Fabric PRINT DLA67816SF
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc..
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..
