SSB Triple Layer Paper Making Forming Fabric with Two over Five Shed Shute Binding Weave and 2 to 1 CD Yarn Ratio for High Sheet Support

All Category

Kraft & Packaging Grades (Brown Paper)

Fruit Juice Dewatering & Pressing

Roll Cover Fabric / Shrink Sleeve

High Speed Fasttrack Cotton Belt

High-Speed Moisture Absorpti On Belt

Honeycomb Cardboard Conveyor Belt

Heat Transfer Printing Nomex Felt Blankets

Decating Felt Blankets and Shrink on Sleeves

Multinip Crown Controlled Calender Machine

Multinip Crown Controlled Soft Calender Machine

Multinip Crown Controlled Heated Calender Machine

Double-Zone Crown Controlled Soft Calender Machine

Paper Making Equipment Consumable Accessories

Doctor Blade & Holder & Air Tube

Suction Roll Seals

Mr. Eric Ding

tinpmc@ahtowin.com

+86 15055187170

Contact Now

SSB Triple Layer Paper Making Forming Fabric with Two over Five Shed Shute Binding Weave and 2 to 1 CD Yarn Ratio for High Sheet Support

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/5 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.13mm 45.4 /cm PET/PA

CMD Yarns Bottom:

0.30mm 22.7 /cm PET/PA

Caliper (mm) New:

0.860

Caliper (mm) Critical:

0.580

Air Permeability:

400 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

166

Fiber Support Point:

1020 /cm²

Drainage Index:

34.5

Paper Side Open Area:

32.0%

Void Volume:

499ml/m²(58.0%)

Basis Weight (g/m²):

480

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer forming fabric

paper making fabric high sheet support

forming fabric two over five shed

Product Description

SSB Triple Layer Paper Making Forming Fabric with Two over Five Shed Shute Binding Weave and 2 to 1 CD Yarn Ratio for High Sheet Support

The PRINT SSB60205YF66-420CFM is a sophisticated SSB triple layer forming fabric engineered with a two over five shed shute binding weave and a 2 to 1 cross direction yarn ratio. The two-shed paper side incorporates paired CD binding yarns that simultaneously provide extra fiber support and securely bind the two independent layers together. The very fine plain weave top surface maximizes sheet support, promoting excellent smoothness and significantly improved formation. High MD and CD stiffness with medium diameter yarns deliver good wear potential and dimensional stability. This fabric is particularly suited for printing and writing papers where surface quality is critical.

Key Features

SSB triple layer forming fabric construction
Two over five shed shute binding weave pattern
2 to 1 cross direction yarn ratio design

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF66
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
