The PRINT SSB55208WM71NG-360CFM is an SSB triple layer forming fabric engineered with a fine plain weave paper side over an eight shed wear side construction. The paper side is finely woven while the wear side is open and coarse, delivering an excellent combination of sheet support, drainage capacity and wear potential. The wear side incorporates a long float design with a 3 to 2 paper side to wear side CD yarn ratio, enabling the use of medium and coarse wear side CD yarns for superior wear resistance. This structure provides high dimensional stability and good life potential. The fabric is particularly suitable for high-speed printing and writing paper production.

Key Features

SSB triple layer forming fabric construction
Plain weave paper side with eight shed wear side
3 to 2 paper side to wear side CD yarn ratio
High number of support points for excellent sheet support

Product Parameters

Product Name	Forming Fabric PRINT SSB55208WM71NG
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
