SSB Forming Fabric High Drainage Featuring Very Fine Plain Weave Top Surface with Maximized Fiber Support and Excellent Formation for Printing Papers

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/5 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.13mm 45.4 /cm PET/PA

CMD Yarns Bottom:

0.30mm 22.7 /cm PET/PA

Caliper (mm) New:

0.860

Caliper (mm) Critical:

0.580

Air Permeability:

400 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

166

Fiber Support Point:

1020 /cm²

Drainage Index:

34.5

Paper Side Open Area:

32.0%

Void Volume:

499ml/m²(58.0%)

Basis Weight (g/m²):

480

Fabric Color:

Light Green, Light Blue

Highlight:

SSB forming fabric high drainage

fine plain weave top surface

printing paper forming fabric

Product Description

SSB Forming Fabric High Drainage Featuring Very Fine Plain Weave Top Surface with Maximized Fiber Support and Excellent Formation for Printing Papers

Designed as a two over five shed SSB triple layer fabric, the PRINT SSB60205YF68-400CFM features a 2 to 1 CD yarn ratio that optimizes the balance between support and drainage. The very fine plain weave paper side provides maximized fiber support for good retention and very high sheet support. High open area enables excellent drainage capacity, allowing rapid water removal without compromising formation quality. The fabric delivers formation improvements and good printability for superior end-product appearance. Medium diameter yarns contribute to good wear potential, while high MD and CD stiffness ensure dimensional stability under dynamic machine conditions.

Key Features

Two-shed paper side with paired CD binding yarns
Independent layers securely bound together
Very fine plain weave top surface

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF68
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
