SSB Triple Layer Cloth with Excellent Sheet Release and Good Printability Offering Very High Sheet Support for Coated Paper Grades

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/5 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.13mm 48.0 /cm PET/PA

CMD Yarns Bottom:

0.30mm 24.0 /cm PET/PA

Caliper (mm) New:

0.865

Caliper (mm) Critical:

0.585

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

173

Fiber Support Point:

1080 /cm²

Drainage Index:

32.9

Paper Side Open Area:

30.3%

Void Volume:

489ml/m²(56.5%)

Basis Weight (g/m²):

500

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer cloth for coated paper

Triple layer cloth with sheet release

SSB cloth for high sheet support

Product Description

SSB Triple Layer Cloth with Excellent Sheet Release and Good Printability Offering Very High Sheet Support for Coated Paper Grades

Engineered with a very fine plain weave top surface, the PRINT SSB60205YF72-360CFM SSB triple layer fabric utilizes a two over five shed shute binding pattern with a 2 to 1 CD yarn ratio. The two-shed paper side features paired CD binding yarns that enhance fiber support and minimize wire marking for superior sheet smoothness. Very high sheet support promotes excellent formation and increased retention. The fabric offers excellent sheet release characteristics that reduce downtime and improve operational efficiency. Good printability results from the improved formation quality. Medium diameter yarns ensure good wear potential with high MD and CD stiffness for dimensional stability.

Key Features

Good printability for superior surface quality
Excellent sheet release minimizing picking issues
High open area for high drainage capacity

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF72
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
