SSB Forming Fabric with Two over Five Shed Shute Binding Structure Providing High Drainage and Minimal Wire Mark for Quality Papers

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/5 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.13mm 48.0 /cm PET/PA

CMD Yarns Bottom:

0.30mm 24.0 /cm PET/PA

Caliper (mm) New:

0.865

Caliper (mm) Critical:

0.585

Air Permeability:

360 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

173

Fiber Support Point:

1080 /cm²

Drainage Index:

32.9

Paper Side Open Area:

30.3%

Void Volume:

489ml/m²(56.5%)

Basis Weight (g/m²):

500

Fabric Color:

Light Green, Light Blue

Highlight:

SSB forming fabric high drainage

SSB fabric minimal wire mark

Triple layer SSB paper fabric

Product Description

SSB Forming Fabric with Two over Five Shed Shute Binding Structure Providing High Drainage and Minimal Wire Mark for Quality Papers

The PRINT SSB60205YF78-300CFM features a very fine SSB triple layer construction with two over five shed shute binding and a 2 to 1 CD yarn ratio. The plain weave paper side with paired CD binding yarns delivers maximized fiber support, achieving very high sheet support with minimal wire mark. High open area facilitates excellent drainage capacity for efficient water removal. Formation quality is significantly improved, resulting in good printability and excellent sheet release. Medium diameter yarns on the wear side provide good wear potential, while high MD and CD stiffness ensure excellent dimensional stability under load. This fabric is well suited for printing and writing papers and coated fine paper grades.

Key Features

High MD stiffness for dimensional stability under load
High CD stiffness for dimensional stability under speed
Medium yarn diameter for good wear potential

Product Parameters

Product Name	Forming Fabric PRINT SSB60205YF78
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Board Grades top layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Board Grades top layer, etc.
