SSB Triple Layer Paper Making Forming Fabric with Two Shed Paper Side and Ten Shed Wear Side Offering Excellent Sheet Support and Drainage

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/10 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.15mm 42.6 /cm PET/PA

CMD Yarns Bottom:

0.35mm 21.3 /cm PET/PA

Caliper (mm) New:

1.050

Caliper (mm) Critical:

0.730

Air Permeability:

380 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

159

Fiber Support Point:

960 /cm²

Drainage Index:

30.9

Paper Side Open Area:

31.7%

Void Volume:

601ml/m²(56.7%)

Basis Weight (g/m²):

610

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer forming fabric

paper making fabric with excellent drainage

two shed paper side fabric

Product Description

SSB Triple Layer Paper Making Forming Fabric with Two Shed Paper Side and Ten Shed Wear Side Offering Excellent Sheet Support and Drainage

The PRINT SSB 60210WM60-400CFM is an SSB triple layer forming fabric engineered with a fine two shed paper side over a ten shed wear side construction. The paper side delivers even and fine surface profiles, while the wear side features an open, long float design that offers an excellent combination of sheet support, drainage capacity and wear potential. The 3 to 2 forming side to wear side CD shute ratio enables the use of medium and coarse CD yarns on the wear side for improved life potential. Two MD thread systems provide stable construction with high CD stability. This fabric is particularly suited for printing and writing paper grades.

Key Features

SSB triple layer forming fabric construction
Two shed paper side for fine sheet support
Ten shed wear side with open structure
Long float wear side for enhanced wear resistance

Product Parameters

Product Name	Forming Fabric PRINT SSB 60210WM60
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
