Designed as a two over ten shed SSB triple layer, the PRINT SSB 60210WM64-360CFM incorporates a long float wear side with a 3 to 2 CD shute ratio between forming and wear sides. This design allows medium and coarse CD yarns on the wear side to deliver exceptional life potential and excellent stability. The even and fine paper side provides good fiber support for uniform formation and consistent sheet profiles. The open structure facilitates high dewatering capacity and easy showering for efficient machine operation. Two MD thread systems contribute to a stable construction with high CD stability. This fabric performs reliably in demanding paper production environments.

Key Features

3 to 2 forming to wear side CD shute ratio
Medium and coarse CD yarns on wear side
Even and fine paper side for even profiles
Good fiber support for uniform formation

Product Parameters

Product Name	Forming Fabric PRINT SSB 60210WM64
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
