SSB Triple Layer Forming Wire with Even and Fine Paper Side for Uniform Profiles and Good Fiber Support in Printing Paper Production

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/10 Shed

MD Yarns Top:

0.13mm 30.0 /cm PET

MD Yarns Bottom:

0.21mm 30.0 /cm PET

CMD Yarns Top:

0.15mm 42.6 /cm PET/PA

CMD Yarns Bottom:

0.35mm 21.3 /cm PET/PA

Caliper (mm) New:

1.050

Caliper (mm) Critical:

0.730

Air Permeability:

380 CFM @ 125 Pa

Elongation(50N/cm):

≤0.45%

Break Strength:

≥900 N/cm

Fiber Support Index:

159

Fiber Support Point:

960 /cm²

Drainage Index:

30.9

Paper Side Open Area:

31.7%

Void Volume:

601ml/m²(56.7%)

Basis Weight (g/m²):

610

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer forming wire

forming wire for printing paper

fine paper side forming wire

Product Description

SSB Triple Layer Forming Wire with Even and Fine Paper Side for Uniform Profiles and Good Fiber Support in Printing Paper Production

The PRINT SSB 60210WM68-320CFM features a fine two shed over ten shed shute binding SSB triple layer design with a 3 to 2 forming to wear side CD yarn ratio. The paper side is even and fine, promoting good fiber support and uniform formation quality. The open, long float wear side creates an open structure that enables high dewatering capacity and easy showering, reducing downtime for cleaning. Two MD thread systems and high CD stability ensure a stable construction that maintains dimensional integrity under operational loads. Medium CD yarns with long float design deliver exceptional life potential. This fabric is ideal for printing and writing paper applications.

Key Features

Open structure for high dewatering capacity
Easy showering for efficient machine cleaning
Stable construction with two MD thread systems
High CD stability for dimensional stability

Product Parameters

Product Name	Forming Fabric PRINT SSB 60210WM68
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing paper, Light Weight Kraft, Wrapping and Packaging Papers, Board Grades top layer, under-top layer or back layer, etc.
