SSB Triple Layer High Wear Potential Paper Making Cloth KRAFT SSB60210WM52-430CFM – Open Structure SSB Fabric with Medium CD Yarns & Easy Showering

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

Pattern Description:

Mesh × Count (l/cm):

Warp Diameter (mm):

Weft Diameter (mm):

Warp Material:

Air Permeability:

Caliper (mm):

Elongation(50N/cm):

Break Strength:

Fiber Support Index (FSI):

Drainage Index (DI):

Open Area:

Fabric Color:

Highlight:

SSB triple layer paper making cloth

high wear potential SSB fabric

open structure kraft SSB60210WM52

Product Description

SSB Triple Layer High Wear Potential Paper Making Cloth KRAFT SSB60210WM52-430CFM – Open Structure SSB Fabric with Medium CD Yarns & Easy Showering

The KRAFT SSB60210WM52-430CFM is a triple layer forming cloth that uses two sheds on the paper side and ten sheds on the wear side. The fine and even paper side provides good fiber support to achieve uniform formation and consistent profiles. Long floats on the wear side, paired with a 3:2 CD shute ratio, allow the integration of medium and coarse CD yarns, significantly improving wear life and machine direction stability. Two MD thread systems ensure high CD stability and a rigid construction. An open structure enables high dewatering capacity and easy showering. This fabric excels in combining sheet support, drainage, and wear potential for paper machine applications.

Key Features

Long float design on wear side extends running potential.
Good fiber support achieves uniform paper formation with minimal marking.
Open fabric structure enables rapid dewatering and easy shower cleaning.

Product Parameters

Product Name	Forming Fabric KRAFT SSB60210WM
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
