SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB44210WC45-475CFM : SSB Triple Layer with 3:2 CD Yarn Ratio for High Dewatering & Dimensional Stability

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/8 Shed

MD Yarns Top:

MD Yarns Bottom:

CMD Yarns Top:

CMD Yarns Bottom:

Caliper (mm) New:

1.330

Caliper (mm) Critical:

Air Permeability:

450CFM, 7100 M³ /m²h 420CFM, 6636 M³ /m²h

Elongation(50N/cm):

≤0.40%

Break Strength:

≥1200 N/cm

Fiber Support Index:

111/116

Fiber Support Point:

461/492 /cm²

Drainage Index:

25.7/25.6

Paper Side Open Area:

32.5/30.7%

Void Volume:

Basis Weight (g/m²):

Fabric Color:

Light Blue, Light Green

Highlight:

SSB triple layer forming fabric

Kraft paper machine fabric

High dewatering forming fabric

Product Description

SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB44210WC45-475CFM : SSB Triple Layer with 3:2 CD Yarn Ratio for High Dewatering & Dimensional Stability

Designed for aggressive paper making conditions, KRAFT SSB44210WC45 uses a plain weave paper side over an eight‑shed wear side in a triple layer configuration. The fine paper side ensures a high fiber support index and numerous support points, which minimizes marking and promotes a clean run with superior mechanical retention. Its wear side features a long float and a 3:2 CD yarn ratio (paper to wear side), allowing the use of medium and coarse CD yarns for excellent wear resistance and dimensional stability. The fabric’s open structure and high internal void volume provide high dewatering capacity. This model balances sheet support, drainage, and wear potential for reliable performance.

Key Features

High Fiber Support Index (FSI) for excellent fiber retention.
Lowest marking level for clean sheet release.

Product Parameters

Product Name	Forming Fabric KRAFT SSB44210WC45
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
