SSB Triple Layer KRAFT SSB45208WC45NG-460CFM Forming Fabric for High Speed Paper Making – 3:2 CD Ratio, Excellent Drainage & Wear Potential with Low Marking Level

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/8 Shed

MD Yarns Top:

MD Yarns Bottom:

CMD Yarns Top:

CMD Yarns Bottom:

Caliper (mm) New:

1.330

Caliper (mm) Critical:

Air Permeability:

450CFM, 7100 M³/m²h

Elongation(50N/cm):

≤0.40%

Break Strength:

≥1200 N/cm

Fiber Support Index:

111/116

Fiber Support Point:

461/492 /cm²

Drainage Index:

25.7/25.6

Paper Side Open Area:

32.5/30.7%

Void Volume:

Basis Weight (g/m²):

Fabric Color:

Light Blue, Light Green

Highlight:

Triple layer KRAFT forming fabric

High speed paper making fabric

SSB45208WC45NG drainage forming fabric

Product Description

SSB Triple Layer KRAFT SSB45208WC45NG-460CFM Forming Fabric for High Speed Paper Making – 3:2 CD Ratio, Excellent Drainage & Wear Potential with Low Marking Level

The KRAFT SSB45208WC45NG SSB triple layer fabric uses a plain weave paper side over an eight‑shed wear side. The fine paper side offers a high number of support points and a high FSI, which guarantees very low marking levels, a clean run, and excellent mechanical retention. Its wear side incorporates a long float and a 3:2 CD yarn ratio (paper side to wear side), allowing medium and coarse CD yarns to achieve excellent wear potential and dimensional stability. The fabric’s high internal void volume together with its surface properties enables excellent dewatering capacity. This design also provides high structural stability and good life potential, making it ideal for paper machines requiring superior sheet support and drainage.

Key Features

Superior mechanical retention minimizes fiber loss and improves formation consistency.
High internal void volume combined with surface properties delivers exceptional water removal.

Product Parameters

Product Name	Forming Fabric KRAFT SSB45208WC45NG
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
