KRAFT SSB44210WL42 is a coarse SSB triple layer forming cloth with a plain weave paper side and an eight‑shed wear side. The paper side offers a high density of support points and a high FSI, achieving the lowest marking levels, clean operation, and strong mechanical retention. The wear side incorporates an open, coarse design with a 3:2 CD yarn ratio, enabling medium and coarse yarns to deliver excellent wear potential and dimensional stability. High internal void volume combined with favorable surface properties yields exceptional dewatering capacity. This fabric also provides good life potential and structural stability, making it a strong choice for paper machines that prioritize formation quality and drainage efficiency.

Key Features

Clean run performance with reduced contamination.
Excellent mechanical retention properties.

Product Parameters

Product Name	Forming Fabric KRAFT SSB44210WL42
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc

Tags:

Board Grades Forming Fabrics

Wrapping Papers Forming Fabrics

Triple layer Forming Fabrics

SSB Triple Layer KRAFT SSB45208WC45NG-460CFM Forming Fabric for High Speed Paper Making – 3:2 CD Ratio, Excellent Drainage & Wear Potential with Low Marking Level

Get Best Price

SSB Triple Layer Durable Paper Machine Fabric KRAFT SSB55208WM55NG-450CFM Fine Paper Side with Coarse Wear Side, High Internal Void Volume for Aggressive Dewatering

Get Best Price

SSB Triple Layer KRAFT SSB44210WL39-475CFM Forming Fabric for Paper Industry: Plain Weave Paper Side, 8 Shed Wear Side, High Support Points

Get Best Price

SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB44210WC45-475CFM : SSB Triple Layer with 3:2 CD Yarn Ratio for High Dewatering & Dimensional Stability

Get Best Price

SSB Triple Layer KRAFT SSB44210WC48-445CFM Coarse Plain Weave Forming Fabric – 8 Shed Wear Side, High FSI & Low Marking for Paper Making

Get Best Price

Products Details

Home > Products >

Forming Fabrics

SSB Triple Layer High Void Volume Paper Making Cloth KRAFT SSB44210WL42-445CFM – Open Coarse Wear Side, Excellent Mechanical Retention & Clean Run

All Category

Forming Fabrics

Pulp Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Kraft & Packaging Grades (Brown Paper)

Single Layer

1.5 Layer

Double and Half Layer

Triple Layer / SSB

Publication Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Tissue Grades

Single Layer

Double and Half Layer

Triple Layer / SSB

Speciality Grades

Triple Layer / SSB

Press Felts

Pulp Grades

BOM Double Layer

BOM 1+1+1 Laminated

Kraft & Packaging Grades (Brown Paper)

BOM Double Layer

Dryer Fabrics

Woven with Flat Yarn

Double Cloth Design

Warp Float 1.5 Layer Design

Woven with Round Yarn

Double Layer

Spiral Linked with Flat Yarn

Spiral Linked with Round Yarn

Thin Ring

Small Ring

Middle Ring

Industrial Fabrics

Filter Cloth

Polyester Filter Cloth

Polypropylene Filter Cloth

Vinylon Filter Cloth

Non Woven Fabric

Spunbond/Meltblown

Airlaid

Spunlace

Wire Mesh

Stainless Steel Wire Mesh

Process Belts

Cylinder Mould Wire Mesh

Corrugated Belts

High Speed Fasttrack Cotton Belt

High-Speed Silencing Belt

Filter Belt

Industrial Felt Belts

Food Industry

Conveyor Belts

Stock Preparation Equipment

Pulping Equipment

Refining Equipment

Screening Equipment

Thickening Equipment

Cleaning Equipment

Paper Machine Components

Headbox

Dewatering System

Cover + Dewatering Box

Oscillating Shower

Dryer Cylinder

Rolls

Guide Roll

Suction Couch Roll

Bow Roll / Spreader Roll

Rewinder

Slitter Knife

Cylinder Mould

Paper Making Equipment Consumable Accessories

DDR Disc

Disc Filter Plate

Doctor Blade & Holder & Air Tube

Filter Bag

Paper Carrier Rope

Screen Basket

Screen Basket - Slot Type

Spray Shower / Nozzle

SSB Triple Layer High Void Volume Paper Making Cloth KRAFT SSB44210WL42-445CFM – Open Coarse Wear Side, Excellent Mechanical Retention & Clean Run

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Brand Name:

ATMC

Structure:

SSB Triple Layer

Pattern Description:

2/8 Shed

MD Yarns Top:

MD Yarns Bottom:

CMD Yarns Top:

CMD Yarns Bottom:

Caliper (mm) New:

1.460

Caliper (mm) Critical:

0.980

Air Permeability:

540 - 445 CFM 8532 - 7031m³ /m²h

Elongation(50N/cm):

≤0.40%

Break Strength:

≥1200 N/cm

Fiber Support Index:

96-106

Fiber Support Point:

369-431 /cm²

Drainage Index:

24.7-23.7

Paper Side Open Area:

35.6-31.7%

Void Volume:

Basis Weight (g/m²):

Fabric Color:

Light Green, Light Blue

Minimum Order Quantity:

1pc

Price:

inquiry

Packaging Details:

Standard export ply-wood case

Payment Terms:

L/C,D/A,D/P,T/T

Highlight:

Triple layer paper making cloth

High void volume Kraft paper cloth

Coarse wear side paper making fabric

Product Description

SSB Triple Layer High Void Volume Paper Making Cloth KRAFT SSB44210WL42-445CFM – Open Coarse Wear Side, Excellent Mechanical Retention & Clean Run

Key Features

Clean run performance with reduced contamination.
Excellent mechanical retention properties.

Product Parameters

Product Name	Forming Fabric KRAFT SSB44210WL42
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
