SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/10 Shed

MD Yarns Top:

0.17mm 25.0 /cm PET

MD Yarns Bottom:

0.25mm 25.0 /cm PET

CMD Yarns Top:

0.18mm 29.2 /cm PET/PA

CMD Yarns Bottom:

0.45mm 14.6 /cm PET/PA

Caliper (mm) New:

1.285

Caliper (mm) Critical:

0.860

Air Permeability:

460 CFM @ 125 Pa

Elongation(50N/cm):

≤0.40%

Break Strength:

≥900 N/cm

Fiber Support Index:

117

Fiber Support Point:

550 /cm²

Drainage Index:

25.7

Paper Side Open Area:

36.0%

Void Volume:

759 Ml/m² (59.0%)

Basis Weight (g/m²):

700

Fabric Color:

Light Green, Light Blue

Highlight:

SSB triple layer paper machine fabric

Kraft SSB50210WC48 forming fabric

two shed ten shed shute binding design

Product Description

SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support

The KRAFT SSB50210WC48 is a triple layer forming cloth that combines a two‑shed paper side with a ten‑shed wear side for superior sheet support and drainage. The fine mesh on the paper side promotes uniform formation, while the wear side features long floats and a 3:2 CD shute ratio (forming side to wear side). This arrangement permits the use of medium and coarse CD yarns on the wear side, boosting durability and stability. Two MD thread systems provide excellent cross‑directional stability, reducing fabric distortion. The open weave structure not only enables high dewatering rates but also allows easy showering, making this fabric a reliable choice for paper machines requiring extended running time.

Key Features

Medium CD yarns used on wear side for balanced durability.
Long float design on wear side provides exceptional wear potential.
Good fiber support enables uniform paper formation.

Product Parameters

Product Name	Forming Fabric KRAFT SSB50210WC
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
