SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

SSB Triple Layer

Pattern Description:

2/10 Shed

MD Yarns Top:

0.17mm 25.0 /cm PET

MD Yarns Bottom:

0.25mm 25.0 /cm PET

CMD Yarns Top:

0.18mm 29.2 /cm PET/PA

CMD Yarns Bottom:

0.45mm 14.6 /cm PET/PA

Caliper (mm) New:

1.285

Caliper (mm) Critical:

0.860

Air Permeability:

460 CFM @ 125 Pa

Elongation(50N/cm):

≤0.40%

Break Strength:

≥900 N/cm

Fiber Support Index:

117

Fiber Support Point:

550 /cm²

Drainage Index:

25.7

Paper Side Open Area:

36.0%

Void Volume:

759 Ml/m²(59.0%)

Basis Weight (g/m²):

700

Fabric Color:

Light Green, Light Blue

Highlight:

Triple layer paper making fabric

High dewatering kraft fabric

SSB50210WC45 wear-resistant fabric

Product Description

SSB Triple Layer High Dewatering Paper Making Fabric KRAFT SSB50210WC45-460CFM – Open Structure SSB Triple Layer with Medium CD Yarns for Improved Wear Life

Designed as a standard SSB triple layer fabric, KRAFT SSB50210WC45 utilizes a two‑shed paper side and a ten‑shed wear side. The fine paper side ensures even profiles and good fiber support for consistent sheet formation. On the wear side, long floats paired with a 3:2 CD shute ratio (forming to wear) accommodate medium and coarse CD yarns, thereby improving wear life and machine direction stability. Two MD thread systems enhance overall fabric rigidity. The open structure offers high dewatering capacity and easy showering, reducing downtime for cleaning. This fabric delivers an excellent balance of sheet support, drainage, and wear potential for modern paper making operations.

Key Features

Consistent fiber support reduces sheet marking risks.
Open structure allows high dewatering capacity.
Open weave design facilitates easy showering and cleaning.

Product Parameters

Product Name	Forming Fabric KRAFT SSB50210WC
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
