SSB Triple Layer KRAFT SSB44210WC48-445CFM Coarse Plain Weave Forming Fabric – 8 Shed Wear Side, High FSI & Low Marking for Paper Making

Brand Name:	ATMC
MOQ:	1pc
Price:	inquiry
Packaging Details:	Standard export ply-wood case
Payment Terms:	L/C,D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Structure:

Pattern Description:

Mesh × Count (l/cm):

Warp Diameter (mm):

Weft Diameter (mm):

Warp Material:

Air Permeability:

Caliper (mm):

Elongation(50N/cm):

Break Strength:

Fiber Support Index (FSI):

Drainage Index (DI):

Open Area:

Fabric Color:

Highlight:

Triple Layer Kraft forming fabric

Coarse plain weave paper making fabric

High FSI low marking forming fabric

Product Description

SSB Triple Layer KRAFT SSB44210WC48-445CFM Coarse Plain Weave Forming Fabric – 8 Shed Wear Side, High FSI & Low Marking for Paper Making

SSB44210WC48 is an SSB triple layer forming fabric featuring a coarse plain weave paper side combined with an eight‑shed wear side. The fine paper side delivers a high number of support points and a high FSI (Fiber Support Index), resulting in extremely low marking levels, clean running, and excellent mechanical retention. The open, coarse wear side, paired with a 3:2 paper side to wear side CD yarn ratio, accommodates medium and coarse CD yarns for outstanding wear potential. This structure offers high dimensional stability and good life potential. The fabric’s high internal void volume and surface properties enable excellent dewatering capacity, making it suitable for demanding paper machine positions requiring both sheet support and drainage.

Key Features

Plain weave paper side design.
Eight shed wear side construction.
High number of support points on paper side.

Product Parameters

Product Name	Forming Fabric SSB44210WC48
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	SSB Triple Layer forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
